JK‑BD6A24S6P V23.5: Shared PCB Design & Compact Form‑Factor
Share
JK‑BD6A24S‑6P V23.5 Update: Shared Circuit Board with 24S‑4P, Smaller Size
Quick Take
JK‑BD6A24S‑6P upgrades to V23.5 hardware sharing PCB with 24S‑4P V23.5. Pre‑charge and improved short‑circuit protection are implemented. Size is reduced and mounting holes are modified. Mass‑production starts late September.
The JK‑BD6A24S‑6P receives major hardware upgrade to V23.5.
What Has Changed
- Shared Circuit Board: Adopts the same advanced PCB platform used by 24S‑4P V23.5.
- Pre‑charge Function: Integrated for safer battery system power‑on sequence.
- Enhanced Short‑Circuit Protection: Improved fault‑detection for lithium battery safety.
- Reduced Physical Size: The unit becomes smaller, which will affect existing installation layouts.
Release Schedule: Mass‑production commences late September.
Frequently Asked Questions
-
Q: Does new V23.5 keep original mounting hole positions?
A: No. Overall size shrinks, mounting positions have been revised. -
Q: Which circuit board does the V23.5 hardware use?
A: It shares identical circuit board design with the 24S‑4P V23.5.
